【Diffusers】HiDream-I1 で Text2Image を行ってみる

はじめに

DiffusersにHiDreamというText2Imageモデルが追加されたのでさっそく試してみました。

使用したPC

VRAM使用量が多いようです。RTX 4090を使用しました。

OS		Windows 11
プロセッサ	Core(TM) i7-14700K
実装 RAM	96.0 GB
GPU		RTX 4090 (VRAM 24GB)

環境構築

pip install torch==2.6.0+cu124 --index-url https://download.pytorch.org/whl/cu124
pip install git+https://github.com/huggingface/diffusers
pip install transformers accelerate
pip install sentencepiece

結果

Pythonスクリプト

以下のスクリプトを用いて様々な条件で実行しました。

import torch
from transformers import PreTrainedTokenizerFast, LlamaForCausalLM
from diffusers import HiDreamImagePipeline, HiDreamImageTransformer2DModel
from typing import Tuple, TypedDict
from itertools import product
import gc
import time

def reset_memory():
    gc.collect()
    torch.cuda.empty_cache()
    torch.cuda.reset_accumulated_memory_stats()
    torch.cuda.reset_peak_memory_stats()

class ResultDict(TypedDict):
    memeory: float
    time_required: float
    combination: str

def main(
    i: int,
    combination: Tuple[bool, bool, bool, bool, bool]
) -> ResultDict:

    if combination[1] == False: # enable_model_cpu_offload() must be true
        return None

    if combination[2] == False: # enable_sequential_cpu_offload() must be true
        return None

    tokenizer_4 = PreTrainedTokenizerFast.from_pretrained(
        "meta-llama/Meta-Llama-3.1-8B-Instruct"
    )

    text_encoder_4 = LlamaForCausalLM.from_pretrained(
        "meta-llama/Meta-Llama-3.1-8B-Instruct",
        output_hidden_states=True,
        output_attentions=True,
        torch_dtype=torch.bfloat16
    )

    transformer = HiDreamImageTransformer2DModel.from_pretrained(
        "HiDream-ai/HiDream-I1-Dev",
        subfolder="transformer",
        torch_dtype=torch.bfloat16
    )

    pipe = HiDreamImagePipeline.from_pretrained(
        "HiDream-ai/HiDream-I1-Dev",
        tokenizer_4=tokenizer_4,
        text_encoder_4=text_encoder_4,
        transformer=transformer,
        torch_dtype=torch.bfloat16,
    )

    try:
        combination_list = []
        if combination[0]:
            pipe.to("cuda")
            combination_list.append("to(\"cada\")")
        if combination[1]:
            pipe.enable_model_cpu_offload()
            combination_list.append("enable_model_cpu_offload()")
        if combination[2]:
            pipe.enable_sequential_cpu_offload()
            combination_list.append("enable_sequential_cpu_offload()")
        if combination[3]:
            pipe.enable_vae_slicing()
            combination_list.append("enable_vae_slicing()")
        if combination[4]:
            pipe.enable_vae_tiling()
            combination_list.append("enable_vae_tiling()")

        start_time = time.time()
        image = pipe(
            'A cat holding a sign that says "Hi-Dreams.ai".',
            height=1024,
            width=1024,
            guidance_scale=5.0,
            num_inference_steps=28,
            generator=torch.Generator("cuda").manual_seed(0),
        ).images[0]

        image.save(f"output{i}.png")
        end_time = time.time()

        result: ResultDict = {
            "memory": round(torch.cuda.max_memory_reserved() / 1024**3, 2),
            "time_required": round(end_time - start_time, 2),
            "combination": "\n".join(combination_list)
        }

    except Exception as e:
        print("\n".join(combination_list))
        print(e)
        return None

    print("succeee!!")
    print("\n".join(combination_list))
    print(f"saved video as output{i}.png")
    return result

if __name__=="__main__":

    combinations = list(product([True, False], repeat=5))

    result_list = []
    for i, combination in enumerate(combinations):
        reset_memory()
        result = main(i, combination)
        if result is not None:
            result_list.append(result)

    print("Sorted by time taken")
    time_sorted_list = sorted(result_list, key=lambda x: x["time_required"])

    for time_sorted in time_sorted_list:
        print(time_sorted["combination"])
        print(f"time: {time_sorted["time_required"]} sec")
        print(f"memory: {time_sorted["memory"]} GB")
        print()

    print("Sorted by memory used")
    memory_sorted_list = sorted(result_list, key=lambda x: x["memory"])

    for memory_sorted in memory_sorted_list:
        print(memory_sorted["combination"])
        print(f"memory: {memory_sorted["memory"]} GB")
        print(f"time: {memory_sorted["time_required"]} sec")
        print()

ベンチマーク結果

かかった時間でソート

enable_model_cpu_offload()
enable_sequential_cpu_offload()
time: 120.92 sec
memory: 3.07 GB

enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
time: 121.53 sec
memory: 3.07 GB

enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_tiling()
time: 121.65 sec
memory: 3.07 GB

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_tiling()
time: 137.86 sec
memory: 58.26 GB

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
time: 139.09 sec
memory: 58.26 GB

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
time: 139.11 sec
memory: 58.26 GB

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
enable_vae_tiling()
time: 151.46 sec
memory: 58.26 GB

enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
enable_vae_tiling()
time: 168.88 sec
memory: 3.07 GB

VRAM使用量でソート

enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
enable_vae_tiling()
memory: 3.07 GB
time: 168.88 sec

enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
memory: 3.07 GB
time: 121.53 sec

enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_tiling()
memory: 3.07 GB
time: 121.65 sec

enable_model_cpu_offload()
enable_sequential_cpu_offload()
memory: 3.07 GB
time: 120.92 sec

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
enable_vae_tiling()
memory: 58.26 GB
time: 151.46 sec

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_slicing()
memory: 58.26 GB
time: 139.11 sec

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
enable_vae_tiling()
memory: 58.26 GB
time: 137.86 sec

to("cada")
enable_model_cpu_offload()
enable_sequential_cpu_offload()
memory: 58.26 GB
time: 139.09 sec
